Product Overview
Product Overview
Waste management process is essential for healthcare institutions striving to prevent and combat hospital-acquired infections and other biohazards. SAMBION has developed the Microwave Incineration range to meet the needs of NOT ONLY medical centers, clinics, hospitals but also Large Kitchens & General Household Wastes, of nearly all sizes generating anywhere from a few kilos to several tones of biohazardous waste per day.
Specifications
Technical Specifications
Inner Parts
Inner parts are of refractory lines & duly insulated with SS cladding
PLC Control Panel
Fully automated machine with PLC control panel and online printer
Duty Cycle Options
Yellow Bag Waste
- Loading
- Heating & Microwave Sterilization
- Exhaust through Wet Scrubber
- Drying/Cooling Cycle
- Shredding/ Mutilation
- Unloading
Red Bag Waste
- Loading
- Vacuum Purging by HEPA Filters
- Shredding/ Mutilation
- Heating & Microwave Sterilization
- Exhaust through Wet Scrubber
- Drying/Cooling Cycle
- Unloading
Shredding Cycle (Only)
- Loading
- Disinfection
- Shredding/ Mutilation
- Unloading
Microwave Operating Frequency
2450 MHz (+/- 10%)
Multiple Microwave Generators
Multiple Microwave Generators (SAMBION Technology)
Working Temperature
- Yellow Bag Waste:350°C
- Red Bag Waste: 100°C (+/- 3%)
Working pressure (max)
Atmospheric
Flue gas Scrubbing/ Odor Masking
Provided
Cycle Timing
- Yellow Bag Waste – 60 minutes
- Red Bag Waste – 35 minutes
Microprocessor PLC (Color Touch Screen) controlled Operations Pre-programmed cycle options, as follows:
- F1 – Yellow Bag Cycle with Shredding @ 100-350°C
- F2 – Red Bag Cycle with Shredding @ 100°C
- F3 – BMW Waste Cycle without Shredding @ 100°C
- F4 – Shredding Cycle
- F5 – Leakage Test
- F6 – Operator’s Choice
Microwave Sterilization
This technology combines shredding with microwave sterilization.
Ultra-compact and Automated
Sambion machines are ultra- compact and completely automated. No prior segregation of waste is required. All types of clinical by-products are Sterilized, Inert and Unrecognizable waste within its single, unique chamber.
Sterilization
Sambion solutions provide traceability, safety and a guaranteed level of sterilization and massive reduction in the cost of waste treatment & disposal as compared to other standard solutions (collection, incinerators, autoclaves, chemicals).
Complies With All International Regulations
The Sambion complies with all international regulations on rendering clinical waste safe (STAATT recommendations)
Power required
3Phase x 415V x 50Hz
Manufactured In India
The equipment is manufactured in India.
