Specifications
Technical Specifications
Inner Parts
All inner parts are of Stainless Steel quality AISI 304/316/ 316L or above
Control Panel
Automatic PLC panel with multi – cycle option with auto corrections
Chamber
Chamber made from SS 304 – Mirror Polished
Steam / Moisture Generator
Steam/ Moisture generator boiler SS 304
Jacket
Jacket made from SS 304
Vacuum Pump
High Vacuum Pump – Heavy Duty x 02 Nos.
Loading Trolley
SS Loading Trolley 1 No.
Excess ETO Removal System
Excess ETO removal System
Operating Temperature
Operating Temperature between 30⁰ – 65⁰ C
ETO Feeding
ETO feeding through Standard ETO+CO2 bulk Cylinder(automatic)
Gasket
High quality Silicon Gasket
Conditioning
Pre & post Conditioning is done in the same chamber
Door Mechanism
Door: Double door & Auto door models are available for clean room applications
Operating Cost
Low cost per cycle: Lowest operating costs compared to other available options
Design & Customization Variables
ALL INDUSTRIAL ETO STERILIZERS ARE DESIGNED AND BUILT AS PER CUSTOMER’S REQUREMENTS TAKING INTO CONSIDERATION THE FOLLOWING VARIABLES
Door Options
All machines are available with conventional hinged doors, or Modern Automatic sliding door options. Conventional Centrally locked Manual doors Or Modern horizontal / Vertical Sliding doors
Gas Mixture
Kind of ETO:CO2 Mixture (Lean / Concentrated) to be used.
Material of Construction (MOC)
The MOC (Material of Construction) is decided taking into consideration, whether it is for Medical Devices or for sterilizing Food or Spices.
Utility & Voltage Availability
Location differences in availability of electricity and operational voltages are considered when designing machines.
Regional Standards
Existing standards for operation / gas release etc. in the country / region where the machine is to be installed.
Performance & Efficiency
Machines are designed for optimums performance while ensuring lowest operational cost.
Testing & Compliance
All Machine are built and tested as per Existing international standards.
Full Datasheet
Major Specification Table
Produced as model Sambion200 Series specifications
| Capacity (L) | 500 | 650 | 850 | 1250 | 2000 | 3000 | 4000 | 4500 | Custom Designed |
|---|---|---|---|---|---|---|---|---|---|
| Chamber Size WxHxD mm |
660 x 660 x 1250 |
660 x 660 x 1500 |
660 x 925 x 1500 |
925 x 925 x 1500 |
925 x 925 x 2500 |
1050 x 1050 x 3000 |
1050 x 1250 x 3100 |
1250 x 1250 x 3000 |
150-5000L |
| Chamber Material | SS316L/ 304 | ||||||||
| Sterilization Temperature |
35-60°C | ||||||||
| PLC + HMI Control | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ |
| Vacuum Drying | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ |
| Single / Double Door | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ |
| Steam Generator | External | ||||||||
| Thermal Printer | Provided | ||||||||
| Automation Grade | Automatic / Manual | ||||||||
| Phase | Three Phase | ||||||||
| Gas | ETO + CO2 Mixture – Bulk Cylinders | ||||||||
| Applications | Industrial ETO Sterilization | ||||||||
| Manufacture License |
CDSCO | ||||||||
| Standards | BIS – IS:3829 Latest Edition with ISI mark | ||||||||
| Certificates: | IAF, NABCB, NSIC, MSME, ISO, CE (MDD), CE (PED), ISO 13485, ISO 9001 etc. | ||||||||
| ↓ Brochure | Download | Download | Download | Download | Download | Download | Download | Download | |
