ETO (ETHYLENE OXIDE) STERILIZERS

Inner Parts

All inner parts are of Stainless Steel quality AISI 304/316/316L or above

PLC Control Panel

Fully automatic machine with PLC panel

Sliding/Hinged Door Mechanism

Automatic single sliding/Hinged door mechanism

Silicon Gasket

High quality Silicon Gasket

ETO Removal System

Excess ETO removal System

Operating Temperature

Operating Temperature between 30°-65° C

ETO Cartridge

With Standard ETO Cartridge or bulk Cylinder

Cartridge puncturing

Cartridge puncturing – inside the chamber

Conditioning

Pre & post conditioning is done in the main chamber only

Sterilization

During Sterilization a Microprocessor / PLC controls temperature, Moisture, Gas Injection, Gas Exposure and all critical time and pressure based parameters.

Air Pollution Control Device

Air Pollution Control Device Catalytic Converter System is provided

PLC controlled Digital panel

PLC controlled Digital panel display Operations : 4-8+ Pre-programmed cycle options, with one touch operation, as follows (which can be programmed depending upon heat & moisture sensitivity of instruments) Wrapped Instruments, Normal Cycle, Rapid process for single, open instrument, Leakage Test, (NO LIQUIDS are allowed in the Chamber)

Error Code and alarm

Error Code and alarm is generated and cycle stops automatically in case any error occurs. Computer Screen displays Error and possible cause and remedy

Reports

Reports are available in Data, Summary and/or Graph formats for every batch of goods sterilized.

Re-print reports

User can re-print reports as and when required, using any normal printer.

Digital storage

Digital storage of data cuts cost, saves space, ensures safety of data and negates cost of expensive thermal printing.

Temperature, Humidity and Pressure

Continuous display of Temperature, Humidity and Pressure On-line allows user to be aware of Cycle status at all times.

User-defined cycles

Cold Cycle (40°C), Warm Cycle (55°C), 7 more user-defined cycles available.

ETO gas cartridges

100% ETO gas cartridges use exact dosage “as per chamber size”. No bulky cylinders to be used by inexperienced personnel, causing leakages and hence health and FIRE & SAFETY hazards.

ETO gas cartridges

ETO gas cartridges is punctured in the chamber only when proper negative pressure and humidity conditions are achieved in the chamber.

Uses

Ethylene Oxide (ETO) sterilization is mainly used to sterilize medical and pharmaceutical products that cannot support conventional high temperature steam sterilization – such as devices that incorporate electronic components, plastic packaging or plastic containers.
